| 序号 | 指标名称 | 单位 | 指标值 | |||||||||
| 1 | 厚度 | 标称值 | mm | 0.05 | 0.08 | 0.13 | 0.18 | 0.25 | 0.30 | 0.38 | 0.51 | 0.76 |
| 偏差 | ±0.005 | ±0.006 | ±0.008 | ±0.02 | ±0.03 | ±10% | ±10% | ±10% | ±10% | |||
| 2 | 定量 | 标称值 | g / m2 | 39 | 63 | 114 | 175 | 240 | 306 | 363 | 498 | 670 |
| 偏差 | ±4 | ±4 | ±6 | ±10 | ±10 | ±20 | ±22 | ±32 | ±50 | |||
| 4 | 抗张强度 | 纵向 | N/10mm | 25 | 40 | 90 | 150 | 200 | 302 | 380 | 450 | 672 |
| 横向 | 10 | 15 | 35 | 55 | 80 | 156 | 180 | 200 | 476 | |||
| 5 | 伸长率 | 纵向 | % | 4 | 5 | 6 | 7 | 9 | 7.5 | 8 | 9 | 9 |
| 横向 | 4 | 4 | 5.5 | 6 | 7 | 5 | 6 | 7 | 7 | |||
| 6 | 介电强度 | KV/mm | 8 | 8 | 8 | 8 | 9 | 9 | 9 | 9 | 9 | |
| 7 | 击穿电压 | V/mil | 230 | 260 | 400 | 450 | 355 | 325 | 287 | 403 | 354 | |
